Cold Room PVC Frame Hinged Door
Produced in conformity with cold room and freezer room conditions.It conforms to European Union norms and manufactured with CE marking. We can produce custom cold room PVC hinged doors with the specifications you need. Our PVC hinged doors highly insulated and comes with high quality parts.
- Environmentally Friendly
- Certified Products
- Energy Saving
- Does not contain carcinogenic material
- Can be used in health and food sector
Examine the Product in Detail
General Specifications
Technical Specifications
General Specifications
Our cold room hinded doors comes with aluminum frame and have some PVC parts to break heat Exchange standartly, as an option full PVC frame is also available. Door leafs are inset type, external metal sheet thickness is 0.8mm and internal metal sheet thickness is 0.5mm, the color code is Ral 9002 for surface metal and door leaf insulation chemical density is 42-45 gr/cm3. The door leaf thickness standart is 8cm for chiller rooms and 10cm for freezer rooms. Also door threshold and sight glass can add as an options.
Technical Specifications
| Door Frame : | PVC |
| Leaf Frame Specifications : | 6063 Grade Aluminum |
| Door Insulation Level : | 42-45gr/cm3 |
| Surface Materials Types : | Polyester-PVC-CrNi |
| Color : | RAL 9002 |
| Pattern : | Flat |
| Insulation : | Poliurethane |
| Sheet Thickness (mm) : | Interior 0,50 mm Exterior 0,50 mm |
| Options : | Silicon Resistance (for Freezer Rooms) |
